The Auto 009

Full Auto BB Pistol

How do I operate the Auto 009?

Press the magazine release button on the left side and remove the magazine.

Using the provided hex key, unscrew the CO2 plug.

Add a drop to the tip of the CO2 cylinder and insert.

Screw in the plug until the CO2 is pierced and sealed. Do not overtighten.

Load the magazine by pulling the follower down and moving it to the side to lock it in place.

Tilt the magazine downward and insert 18 BBs.

Release the follower.

The magazine can now be inserted, press until it clicks.

Pull the slide back and release it. Your pistol is now ready to fire.

How do I use my sights correctly?

Align the front sight in the rear slot with the target sitting on top. The sights are fixed, so if point of impact differs from the point of aim, try cleaning the barrel and/or switching brand of BBs to get the best accuracy.

How do I field strip the 009?

Remove the magazine. Pull the slide back and lock it in place. Lower the take down, release the slide lock, and push the slide off.

Remove the recoil spring. Remove the barrel.



Note: If you break, damage, or lose any part of your gun during this process it will void the warranty. Please contact help@barraairguns.com if you have any questions in regards to field stripping your gun.

How do I reassemble the 009?

Install the barrel. Install the recoil spring. Align the slide with the rails and pull it back. Release it and dry fire. Your 009 is now reassembled.



Note: Taking apart and reassembling your gun is not part of the regular use of your gun and could void the warranty. Please contact help@barraairguns.com if you have any questions in regards to reassembling your gun.

How do I adjust the hop up?

Field strip your 009. If your 009 is shooting upward, reduce the hop up to flatten the trajectory.



Note: If you break, damage, or lose any part of your gun during this process it will void the warranty. Please contact help@barraairguns.com if you have any questions in regards to this before attempting it yourself.

What do i do if my gun isn't shooting accurately?

Many of these guns shoot about 2 inches low.

Unfortunately there isn't a way to adjust the elevation accuracy without physically altering the sights. Installing a laser is probably the easiest way to get around this issue.

We are aware of this issue and are working to manufacture a more accurate gun. There is no timeline for this yet, unfortunately. Hopefully you enjoy the gun regardless!
